[Goal]

  • OpenCV 기반 panorama stitching 을 진행할 때 시간 소요가 많이 걸리는데, 많이 소요되는 시간을 판단해보고 빠르게 stitching할 수 있는 방법들을 확인해볼 수 있다.

[Reference Site]

[Basic Procees]

(1) Find Features

  • 이미지들간 연관성이 있는지 파악하기 위해 먼저 이미지들의 feature들을 extraction 및 이들간의 관계를 파악하기 위해 descriptor 계산

(2) Match Features

  • 이미지들간의 feature 및 descriptor 들을 이용하여 연관성을 계산
  • 여기서 연관성은 confidence 라는 명칭을 사용하고 이들은 feature matching 된 개수를 이용하여 계산
confidence = number of inliers / (8 + 0.3 * number of matches)

// Output
/* array([[0.        , 2.45009074, 0.56      , 0.44247788],
          [2.45009074, 0.        , 2.01729107, 0.42016807],
          [0.56      , 2.01729107, 0.        , 0.38709677],
          [0.44247788, 0.42016807, 0.38709677, 0.        ]]) */
[해석]
이미지 1은 이미지 2와 가장 큰 연관성을 가지고 있다.
이미지 2는 이미지 1 & 이미지 3과 높은 연관성을 가지고 있다.
이미지 3은 이미지 2와 높은 연관성을 가지고 있다.
이미지 4는 이미지 1, 2, 3 모두 연관성이 높지 않다.

(3) Subset

  • 위에 계산된 confidence를 기반하여 stitching할 이미지들을 연결짓는 작업 진행
  • `Default Confidence Threshold: 1`
  • Results
graph matches_graph{
 "weir_1.jpg" -- "weir_2.jpg"[label="Nm=157, Ni=135, C=2.45009"];
 "weir_2.jpg" -- "weir_3.jpg"[label="Nm=89, Ni=70, C=2.01729"];
 "weir_noise.jpg";}
  • 이를 통해 image 4는 weir_noise로 분류되어 panorama stitching 에 사용되지 않음
  • 나머지 연결될 이미지들을 기반하여 confidence를 다시 계산
  • Results
['imgs\\weir_1.jpg', 'imgs\\weir_2.jpg', 'imgs\\weir_3.jpg']
[[0.         2.45009074 0.56      ]
 [2.45009074 0.         2.01729107]
 [0.56       2.01729107 0.        ]]

(4) Camera parameter estimation

  • 정확한 wraping을 위해서 camera parameter을 계산
  • `CameraEstimator, CameraAdjuster, and WaveCorrector`

(5) Warp images

  • 최종적으로 옮겨질 plane으로 옮겨질 곳으로 이미지들을 warp진행

(6) Find Seam

  • 이미지들을 결합시키기 위해서 결합할 이미지들간 경계선을 찾는 작업을 진행

(7) Exposure Error Compensation

  • 연결될 이미지들의 exposure가 다르기 때문에 이들을 맞춰주기 위한 작업을 진행

(8) Blending

  • 파노라마 이미지로 최종 만드는 작업 진행

[High Stitching API in OpenCV C++]

void setRegistrationResol(double resol_mpx) { registr_resol_ = resol_mpx; }
void setSeamEstimationResol(double resol_mpx) { seam_est_resol_ = resol_mpx; }
void setCompositingResol(double resol_mpx) { compose_resol_ = resol_mpx; }
void setPanoConfidenceThresh(double conf_thresh) { conf_thresh_ = conf_thresh; }
void setWaveCorrection(bool flag) { do_wave_correct_ = flag; }
void setInterpolationFlags(InterpolationFlags interp_flags) { interp_flags_ = interp_flags; }
void setWaveCorrectKind(detail::WaveCorrectKind kind) { wave_correct_kind_ = kind; }
void setFeaturesFinder(Ptr<Feature2D> features_finder) { features_finder_ = features_finder; }
void setFeaturesMatcher(Ptr<detail::FeaturesMatcher> features_matcher) { features_matcher_ = features_matcher; }
void setMatchingMask(const cv::UMat &mask) {matching_mask_ = mask.clone();}
void setBundleAdjuster(Ptr<detail::BundleAdjusterBase> bundle_adjuster) { bundle_adjuster_ = bundle_adjuster; }
void setEstimator(Ptr<detail::Estimator> estimator) { estimator_ = estimator; }
void setWarper(Ptr<WarperCreator> creator) { warper_ = creator; }
void setExposureCompensator(Ptr<detail::ExposureCompensator> exposure_comp) { exposure_comp_ = exposure_comp; }
void setSeamFinder(Ptr<detail::SeamFinder> seam_finder) { seam_finder_ = seam_finder; }
void setBlender(Ptr<detail::Blender> b) { blender_ = b; }
// ORB
cv::Ptr<Feature2D> finder = cv::ORB::create();
// AKAZE
cv::Ptr<Feature2D> finder = cv::AKAZE::create();
// SIFT
cv::Ptr<Feature2D> finder = cv::SIFT::create();
// SURF
cv::Ptr<Feature2D> finder = cv::xfeatures2d::SURF::create();
    • Matcher Method
// Affine NN
cv::Ptr<FeaturesMatcher> matcher = cv::makePtr<AffineBestOf2NearestMatcher>(false, try_cuda, match_conf);
// Best kNN
cv::Ptr<FeaturesMatcher> matcher = cv::makePtr<BestOf2NearestMatcher>(try_cuda, match_conf);
// Range NN
cv::Ptr<FeaturesMatcher> matcher = makePtr<BestOf2NearestRangeMatcher>(range_width, try_cuda, match_conf);
    • Camera Estimator Method
// Affine Homography
cv::Ptr<cv::detail::Estimator> estimator = cv::makePtr<AffineBasedEstimator>();
// Homography
cv::Ptr<cv::detail::Estimator> estimator = cv::makePtr<HomographyBasedEstimator>();
    • Bundle Adjustment Method
// Reprojection
cv::Ptr<cv::detail::BundleAdjusterBase> adjuster = cv::makePtr<cv::detail::BundleAdjusterReproj>();
// Ray
cv::Ptr<cv::detail::BundleAdjusterBase> adjuster = cv::makePtr<cv::detail::BundleAdjusterRay>();
// Affine
cv::Ptr<cv::detail::BundleAdjusterBase> adjuster = cv::makePtr<cv::detail::BundleAdjusterAffinePartial>();
// Not use BA
cv::Ptr<cv::detail::BundleAdjusterBase> adjuster = cv::makePtr<NoBundleAdjuster>();
    • Warp Method
// Plane
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::PlaneWarper>();
// Affine
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::AffineWarper>();
// Cylinderical
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::CylindricalWarper>();
// Spherical (Default)
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::SphericalWarper>();
// Fisheye
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::FisheyeWarper>();
// Stereographic
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::StereographicWarper>();
// PaniniA2B1
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::PaniniWarper>(2.0f, 1.0f);
// PaniniPortraitA2B1
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::PaniniPortraitWarper>(2.0f, 1.0f);
// Mercator
cv::Ptr<WarperCreator> warper_creator = cv::makePtr<cv::MercatorWarper>();
    • Exposure Method
// Gain
cv::Ptr<ExposureCompensator> compensator = ExposureCompensator::createDefault(expos_comp_type);
if (dynamic_cast<GainCompensator*>(compensator.get()))
{
    GainCompensator* gcompensator = dynamic_cast<GainCompensator*>(compensator.get());
    gcompensator->setNrFeeds(expos_comp_nr_feeds);
}
// Channel
cv::Ptr<ExposureCompensator> compensator = ExposureCompensator::createDefault(expos_comp_type);
if (dynamic_cast<ChannelsCompensator*>(compensator.get()))
{
    ChannelsCompensator* ccompensator = dynamic_cast<ChannelsCompensator*>(compensator.get());
    ccompensator->setNrFeeds(expos_comp_nr_feeds);
}
// Block
cv::Ptr<ExposureCompensator> compensator = ExposureCompensator::createDefault(expos_comp_type);
if (dynamic_cast<BlocksCompensator*>(compensator.get()))
{
    BlocksCompensator* bcompensator = dynamic_cast<BlocksCompensator*>(compensator.get());
    bcompensator->setNrFeeds(expos_comp_nr_feeds);
    bcompensator->setNrGainsFilteringIterations(expos_comp_nr_filtering);
    bcompensator->setBlockSize(expos_comp_block_size, expos_comp_block_size);
}
    • Seam Method
// Graph Cut (Default)
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::GraphCutSeamFinder>(GraphCutSeamFinderBase::COST_COLOR);
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::GraphCutSeamFinder>(GraphCutSeamFinderBase::COST_COLOR_GRAD);
// Dynamic Programming
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::DpSeamFinder>(DpSeamFinder::COLOR);
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::DpSeamFinder>(DpSeamFinder::COLOR_GRAD);
// Voronoi
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::VoronoiSeamFinder>();
// Not Use
cv::Ptr<SeamFinder> seam_finder = cv::makePtr<detail::NoSeamFinder>();
    • Blender Method
// Feather
cv::Ptr<Blender> blender = cv::Blender::createDefault(blend_type, try_cuda);
cv::FeatherBlender* fb = dynamic_cast<FeatherBlender*>(blender.get());
fb->setSharpness(1.f/blend_width);
blender->prepare(corners, sizes);
// Multi Band
cv::Ptr<Blender> blender = cv::Blender::createDefault(blend_type, try_cuda);
cv::MultiBandBlender* mb = dynamic_cast<MultiBandBlender*>(blender.get());
mb->setNumBands(static_cast<int>(ceil(log(blend_width)/log(2.)) - 1.));
blender->prepare(corners, sizes);
  • Github안 코드부분
// Feature Extraction (cv::Stitcher::Status Stitcher::matchImages())
cv::Ptr<cv::Feature2D> features_finder_;
std::vector<cv::detail::ImageFeatures> features_;
std::vector<cv::UMat> feature_find_imgs(imgs_.size());
std::vector<cv::UMat> feature_find_masks(masks_.size());
**cv::detail::computeImageFeatures(features_finder_, feature_find_imgs, features_, feature_find_masks);**

// Feature Matcher (cv::Stitcher::Status Stitcher::matchImages())
cv::Ptr<cv::detail::FeaturesMatcher> features_matcher_;
std::vector<cv::detail::MatchesInfo> pairwise_matches_;
cv::UMat matching_mask_;
**(*features_matcher_)(features_, pairwise_matches_, matching_mask_);**

// Estimate Camera Parameters & Homography (cv::Stitcher::Status Stitcher::estimateCameraParams())
std::vector<cv::detail::CameraParams> cameras_;
cv::Ptr<cv::detail::Estimator> estimator_;
**if (!(*estimator_)(features_, pairwise_matches_, cameras_))**

// Correction using Bundle Adjustment (cv::Stitcher::Status Stitcher::estimateCameraParams())
****cv::Ptr<cv::detail::BundleAdjusterBase> bundle_adjuster_;
**if (!(*bundle_adjuster_)(features_, pairwise_matches_, cameras_))**

// Warp images (cv::Stitcher::Status Stitcher::composePanorama())
cv::Ptr<cv::WarperCreator> warper_;
double warped_image_scale_;
double seam_work_aspect_;
cv::Ptr<cv::detail::RotationWarper> w = warper_->create(float(warped_image_scale_ * seam_work_aspect_));
**w->warp(masks[i], K, cameras_[i].R, INTER_NEAREST, BORDER_CONSTANT, masks_warped[i]);**

// Compensate exposure
Ptr<detail::ExposureCompensator> exposure_comp_;
std::vector<UMat> masks_warped(imgs_.size());
std::vector<UMat> images_warped(imgs_.size());
std::vector<Point> corners(imgs_.size());
exposure_comp_->feed(corners, images_warped, masks_warped);
**exposure_comp_->apply(int(i), corners[i], images_warped[i], masks_warped[i]);**

// Find Seam
cv::Ptr<cv::detail::SeamFinder> seam_finder_;
std::vector<UMat> images_warped_f(imgs_.size());
**seam_finder_->find(images_warped_f, corners, masks_warped);**

// Blender
cv::Ptr<cv::detail::Blender> blender_;
cv::UMat result;
cv::UMat result_mask_;
blender_->feed(img_warped_s, mask_warped, corners[img_idx]);
**blender_->blend(result, result_mask_);**

[Which one is fast stitching?]

  • Stitching Pair (EuRoC Dataset)
Image 1 Image 2
  • Automatic stitching result → 4.00 sec
  • 여러 API를 건들었을때, 어느 결과가 가장 빠르게 stitching 되었는지 확인해본 결과 다음과 같이 적용할 때, 가장 빠른 것으로 확인 → 0.9 sec
stitcher->setFeaturesMatcher(cv::makePtr<cv::detail::BestOf2NearestMatcher>(false));
stitcher->setBundleAdjuster(cv::makePtr<cv::detail::BundleAdjusterRay>());
stitcher->setExposureCompensator(cv::makePtr<cv::detail::GainCompensator>());
stitcher->setSeamFinder(cv::makePtr<cv::detail::DpSeamFinder>(cv::detail::DpSeamFinder::COLOR));
stitcher->setBlender(cv::makePtr<cv::detail::MultiBandBlender>(false));
    • Stitching 속도를 크게 좌우하는 함수들은 `setExposureCompensator, setSeamFinder` 이다.
  • Automatic하게 Stitching하게 되면 4초의 stitching 시간이 걸리는데, 위의 방법론을 적용하면 0.9초까지 앞당길 수 있다.

[Results]

Original Result → (4.0 sec)
Seam (Dynamic Programming) → (3.2 sec)
Seam (Dynamic Programming) + BA (Affine Partial) → (1.8 sec)
Seam (Dynamic Programming) + BA (Reprojection) → (2.8 sec)
Seam (Dynamic Programming) + Exposure (Gain Compensator) → (0.9 sec)
